| 一、各类集装箱常用技术规范(Container
Technical Data) |
| 1、箱体内部尺寸（ Internal
Dimensions ） |
|
|
干货箱Dry |
冷藏箱Reefer |
开顶箱Open Top |
框架箱Flat Rack |
| L |
W |
H |
L
|
W
|
H
|
L
|
W
|
H
|
L
|
W
|
H
|
| 20' |
5898 |
2352 |
2393 |
5444 |
2284 |
2267 |
5900 |
2330 |
2337 |
5628 |
2178 |
2159 |
| 40' |
12032 |
2352 |
2393 |
11583 |
2284 |
2250 |
12025 |
2330 |
2337 |
11762 |
2178 |
1986 |
| HC |
12032 |
2352 |
2698 |
11583 |
2286 |
2556 |
/ |
/ |
/ |
/ |
/ |
/ |
|
|
| 2、箱体内容积及载重量（ Capacity
& Payload ） |
|
|
干货箱Dry |
冷藏箱Reefer |
开顶箱Open Top |
框架箱Flat Rack |
| Cu |
P |
Cu
|
P
|
Cu
|
P
|
Cu
|
P
|
| 20' |
33.2 |
21740|28230# |
28.5 |
21135|27160# |
32.6 |
21740 |
/ |
27800 |
| 40' |
67.7 |
26630 |
58.7 |
26580 |
65.8 |
26410 |
/ |
40250 |
| HC |
76.3 |
26520 |
67.9 |
26380 |
/ |
/ |
/ |
/ |
|
|
| 3、各类箱箱号首位数之含义 （ Meaning
of the first or the first two digits of container serial number
） |
|
|
干货箱Dry |
冷藏箱Reefer |
开顶箱Open Top |
框架箱Flat Rack |
| 20' |
0 |
3
|
5 |
6 |
8 |
22 |
23 |
25 |
26 |
52 |
92 |
| 40' |
1 | 4 | 7 |
20 |
21 |
24 |
27 |
54 |
94 |
| HC |
96 |
29 |
/ |
/ |
|
|
| 4、箱门开度尺寸 (Door Opening
Dimensions) |
|
| 干货箱Dry |
| 20' |
40' |
HC |
| W |
H |
W |
H |
W |
H |
| 2340 |
2280 |
2340 |
2280 |
2340 |
2585 |
|
|
|
Remark: The dimension
is in MM. Capacity is M3.Weight in Kg.
备注：尺寸：毫米 体积：立方米 质量：千克
#：These containers are manufactured after 2000.
#： 2000年后制造的箱子。
|
|
| 二、特种箱（Special Equipment
Specification） |
|
|
冷藏箱（Reefer） |
| L |
W |
H |
| 20' |
5435 |
2286 |
2245 |
| 40' |
11552 |
2266 |
2200 |
| HC |
11558 |
2286 |
2505 |
|
|
|
开顶箱（Open Top） |
| L
|
W
|
H
|
| 20' |
5900 |
2330 |
2337 |
| 40' |
12025 |
2330 |
2337 |
|
|
|
框架箱(Flat Back) |
| L
|
W
|
H
|
| 20' |
5628 |
2178 |
2159 |
| 40' |
11762 |
2178 |
1986 |
|
